Product Search Result

NAME :

 B-Sharp

PRODUCT IMAGE :

Click On Main Image for Larger View

MANUFACTURER :

Europe Audio Team

SPECIFICATIONS :

Model B-Sharp
Nominal speed 33/45 rpm, manual speed change
Speed variance 33rpm: ± < 0.11%, 45rpm: ± < 0.12%
Wow and flutter 33rpm: ± < 0.08%, 45rpm: ± < 0.07%
Signal to noise S/N Ratio (mechanical noise): - 40 dB S/N
Ration (electrical noise): -68 dB
Downforce range 0 - 30 mN 0 - 3.0 grams

Supplied counterweight system
Counterweight 125 g without additional insert → for cartridges 5 - 9 g
Counterweight with additional insert 142 g →for cartridges 8.5 - 13 g
Effective tonearm mass 12.5 g
Effective tonearm lenght 230 mm
Overhang 18 mm
Power consumption 5 W max/ 0.5W standby

Voltage
Universal swith mode power supply 15 V DC/1.6 A, 90-264 V AC, 47 - 63Hz

Dimensions (W x H x D)
460 x 352 x 125mm without dustcover,
460 x 352 x 142mm closed dustcover
460 x 380 x 435mm opened dustcover
Weight (without box) 8,5 kg (turntable)
Weight (with box) 12 kg


MANUAL:

BROCHURE:

BRIEF DESCRIPTION :

DESCRIPTION :


European Audio Team (E.A.T) announces B-Sharp turntable, with engineered cues taken directly from the company’s award-winning and highly acclaimed C-Major turntable. The B-Sharp sheds all of the non-essential cosmetic adornments of the C-Major without compromising performance or mechanical integrity, providing vinyl enthusiasts with a superb playback option at a more affordable price. The B-Sharp turntable features the new B-Note tonearm, made from a carbon fiber alloy that is light yet rigid with a black anodized aluminum headshell. The B-Note tonearm provides all of the key features for cartridge alignment and adjustability: VTA (Vertical Tracking Angle), SRA (Stylus Rake Angle), VTF (Vertical Tracking Force), azimuth and a slotted headshell for overhang / offset angle. The anti-skate mechanism has been engineered for more intuitive calibration, making setup of the B-Sharp notably easier than competitive products.  A proprietary low noise motor, floating chassis, aluminum platter and a high-density MDF low profile base are included as standard features of the B-Sharp. Like the C-Major, the B-Sharp uses a high-tech TPE (thermoplastic elastomers) suspension system that works in concert with adjustable feet that provide levelling ability for the table. The B-Sharp comes equipped with a factory installed Ortofon 2M Blue Cartridge, hinged dustcover, low mass aluminum record clamp ( in some countries is not included) and a felt platter mat-all included. The B-Sharp delivers a level of performance commensurate with turntables at a significantly higher price Point. And we are confident that the B-Sharp will bring joy and lasting satisfaction to music aficionados everywhere. Factoring in the new tonearm, the easy-to-use anti-skate and the ready-to-play nature of the B-Sharp, we are confident that this product will become an instant classic.
